SKU: WSZC35-JCS
JCS WSZC35 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 25-35mm Band Width 13mm
JCS WSZC35 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 25-35mm Band Width 13mm
Regular price
Rs. 610.00
ex VAT
Regular price
Sale price
Rs. 610.00
ex VAT
In stock
Price Break
10+
Rs. 542.90
19+
Rs. 512.40
29+
Rs. 506.30
39+
Rs. 500.20
49+
Rs. 494.10
74+
Rs. 488.00
99+
Rs. 457.50
199+
Rs. 451.40
249+
Rs. 445.30
499+
Rs. 439.20
999+
Rs. 427.00
Couldn't load pickup availability
Description
Description
Zinc Plated Steel Hi-Grip Wing Screw: Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse.
- Brand / Quality:
- JCS - High Quality
- Width:
- 13mm
- Min Adjustment Range:
- 25mm
- Max Adjustment Range:
- 35mm
Technical
Technical
| BS No. | 35 |
|---|---|
| Adjustment Range (mm) | 25-35mm |
| Adjustment Range (inch) | 1 - 1-3/8 inch |
| A | 8mm |
| B | 32mm |
| C | 12mm |
| D | 15mm |
| E | 13mm |
| F | 0.9mm |
| G | 24mm |
| Recommended Torque Nm | 5Nm |
| Recommended Torque lb-in | 45lb-in |
