Grease Nipples and Fittings

These grease nipples and fittings are commonly used in bearings and machinery, to allow efficient lubrication without mess or waste.

190 products

Loading filters…

Grease Nipples and Fittings

What are grease nipples and fittings?

Grease nipples, also known as grease fittings, zerks, or lubrication nipples, are small threaded fittings that allow grease to be pumped into bearings, joints, pivots, and other moving parts using a grease gun. They are screwed into a threaded hole in the component, giving a clean, sealed entry point for fresh grease. Inside each nipple is a small spring-loaded ball that acts as a one-way valve, letting grease in under pressure while stopping it escaping and keeping dirt, dust, and water out.

Grease nipples are found on almost every type of machinery, from tractors, trailers, and construction equipment to industrial machines, conveyors, vehicles, and garden equipment. They make regular lubrication quick, clean, and simple, helping moving parts last much longer.

A typical grease nipple has:

  • Threaded body - screws into the component, with threads such as M6 × 1, M8 × 1, M10 × 1, 1/8 inch BSP, or 1/4 inch BSP
  • Hexagon - allows the nipple to be tightened or removed with a spanner
  • Head - the rounded top that the grease gun coupler clips onto
  • Check valve - a spring-loaded ball inside the head that lets grease in and keeps dirt out
  • Grease passage - a hole through the centre of the nipple that carries the grease into the component

Key features:

  • Clean, easy lubrication - grease is pumped directly to where it is needed, without mess or waste
  • One-way valve - lets grease in while keeping dirt, dust, and moisture out
  • Sealed entry point - protects the lubrication passage between greasing intervals
  • Range of angles - straight, 45 degree, and 90 degree nipples allow access in tight spaces
  • Range of threads - metric, BSP, UNF, and NPT threads to suit different machines
  • Durable materials - zinc plated steel, stainless steel, and brass options
  • Easy replacement - blocked or damaged nipples can be swapped quickly

In simple terms, a grease nipple is a small fitting that lets you pump fresh grease into a moving part quickly and cleanly, while keeping dirt out.

Why are grease nipples and fittings essential?

Grease nipples are essential because many bearings, pins, bushes, and joints need regular lubrication to work smoothly and last. Without fresh grease, friction increases, parts wear quickly, and dirt and water can get in, causing corrosion and failure. Grease nipples allow fresh grease to be added quickly during routine maintenance, without dismantling the machine, and help push out old, contaminated grease.

Their main benefits are:

  • Longer component life - regular greasing reduces wear on bearings, pins, and bushes
  • Quick maintenance - parts can be lubricated in seconds with a grease gun
  • No dismantling needed - lubricate parts without taking the machine apart
  • Flushes out contamination - fresh grease pushes out old grease, dirt, and water
  • Clean application - grease goes exactly where it is needed, with minimal waste
  • Protection between services - the check valve keeps dirt and moisture out
  • Reduced downtime - well-lubricated machinery is less likely to break down
  • Low cost - inexpensive fittings that protect much more valuable components

Grease nipples are used across a wide range of industries and applications, including:

  • Agricultural machinery - tractors, loaders, trailers, balers, mowers, and implements
  • Construction and plant machinery - excavators, loaders, and dumpers, especially on pins and bushes
  • Industrial machinery - bearings, gearboxes, slides, and pivots
  • Bearing housings - plummer blocks, flange units, and housed bearings
  • Conveyors - rollers, pulleys, and drive bearings
  • Automotive and commercial vehicles - suspension, steering, and prop shaft joints
  • Garden and groundcare equipment - ride-on mowers, deck spindles, and pivots
  • Marine - steering gear, winches, and deck equipment

The main types of grease nipples and fittings

Grease nipples are usually grouped by their head type, angle, thread, and material.

By head type:

  • Hydraulic grease nipples - the most common type, with a rounded head that a standard hydraulic grease gun coupler clips onto. Many follow the DIN 71412 standard
  • Button head grease nipples - have a larger, flat head, used for higher grease volumes and heavier grease, and need a matching button head coupler
  • Flush grease nipples - sit flush or nearly flush with the surface, used where space is very limited
  • Drive-in grease nipples - pressed or hammered into a drilled hole without a thread, often used on light machinery

By angle:

  • Straight grease nipples - the standard type, used where there is good access
  • 45 degree grease nipples - angled to make access easier in awkward positions
  • 90 degree grease nipples - angled at a right angle for tight spaces and hard-to-reach points

By thread:

  • Metric threads - such as M5 × 0.8, M6 × 1, M8 × 1, M10 × 1, and M12 × 1.5, common on European machinery
  • BSP threads - such as 1/8 inch and 1/4 inch BSP, common on British and older machinery
  • UNF threads - such as 1/4 inch UNF, used on American and some older vehicles
  • NPT threads - American tapered pipe threads, used on some imported machinery

By material and finish:

  • Zinc plated steel - the most common type, with white or yellow zinc plating for corrosion protection
  • Stainless steel - resists rust and corrosion, ideal for food processing, marine, and washdown environments
  • Brass - corrosion resistant and suitable for some specialist applications

Related fittings:

  • Connection nipples - adaptors that allow grease nipples to be connected to different threads or fitted in awkward positions
  • Grease nipple extensions - extend the nipple to make it easier to reach
  • Thread adaptors and reducers - convert between different thread sizes and types
  • Grease nipple caps - plastic caps that cover the nipple head to keep dirt out
  • Grease nipple kits - assortments of common nipples in a case, ideal for workshops and maintenance teams

How to choose the right grease nipples and fittings?

Choosing the right grease nipple means matching it to the thread, the space available, and the grease gun you use. Work through these points in order:

  • Thread size and type - identify the thread in the component, such as M6 × 1, M8 × 1, 1/8 inch BSP, or 1/4 inch UNF. Use a thread gauge and calipers, or check the old nipple
  • Thread pitch - check the pitch carefully, as similar-looking threads can have different pitches and will not fit
  • Thread length - make sure the thread length suits the depth of the hole, so the nipple seats correctly
  • Angle - choose straight, 45 degree, or 90 degree nipples to suit the access around the grease point
  • Head type - choose hydraulic nipples for standard grease guns, or button head nipples for heavy-duty, high-volume greasing with a matching coupler
  • Space - choose flush or short nipples where clearance is limited
  • Material - choose zinc plated steel for general use, and stainless steel for wet, corrosive, or hygienic environments
  • Grease gun compatibility - make sure your grease gun coupler fits the nipple head
  • Protection - consider grease nipple caps in dirty environments to keep the heads clean
  • Stock - consider a grease nipple kit if you maintain machines with many different thread sizes
  • Quality and brand - choose nipples from reputable suppliers for accurate threads and reliable check valves

FAQ - All you need to know about grease nipples and fittings

What is a grease nipple?

A grease nipple is a small threaded fitting that allows grease to be pumped into a bearing, joint, or moving part using a grease gun. It has a check valve that lets grease in while keeping dirt out.

How do I know what thread my grease nipple has?

Remove the old nipple and measure the thread diameter and pitch with calipers and a thread gauge, then compare it with a thread chart. Common sizes include M6 × 1, M8 × 1, M10 × 1, 1/8 inch BSP, and 1/4 inch UNF.

What is the difference between straight and angled grease nipples?

Straight nipples point directly out from the component, while 45 and 90 degree nipples are angled to make it easier to connect the grease gun in tight or awkward spaces.

What is the difference between hydraulic and button head grease nipples?

Hydraulic nipples have a small rounded head and work with standard grease gun couplers. Button head nipples have a larger flat head, are used for heavier grease and higher volumes, and need a button head coupler.

Why won’t grease go into the nipple?

Common causes include a blocked nipple, hardened old grease in the passage, a seized check valve, or a blocked grease channel in the component. Try cleaning or replacing the nipple, and check the grease passage is clear.

Can I clean a blocked grease nipple?

Sometimes a blocked nipple can be cleared, but as they are inexpensive, it is often quicker and more reliable to replace it.

How do I fit a grease nipple?

Clean the threaded hole, screw the nipple in by hand, then tighten it with the correct spanner. Do not overtighten, as small threads can strip or snap.

How much grease should I pump in?

Follow the machine manufacturer’s recommendations. As a general guide, pump grease in until fresh grease appears or the old grease is pushed out, but avoid over-greasing bearings with seals, as this can damage the seals and cause overheating.

Should I clean the nipple before greasing?

Yes. Wipe the nipple head clean before connecting the grease gun, so dirt is not pushed into the bearing with the grease.

What are grease nipple caps for?

Caps fit over the nipple head to keep dirt, dust, and water off between greasing intervals, helping keep the nipple and grease gun coupler clean.

How often should grease nipples be replaced?

Replace them when they are damaged, blocked, leaking, or no longer hold the grease gun coupler securely. It is good practice to keep a kit of common sizes on hand for quick replacements.
