SKU: WSZC30-JCS
JCS WSZC30 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 22-30mm Band Width 13mm
JCS WSZC30 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 22-30mm Band Width 13mm
Regular price
Rs. 600.33
ex VAT
Regular price
Sale price
Rs. 600.33
ex VAT
In stock
Price Break
10+
Rs. 534.29
19+
Rs. 504.28
29+
Rs. 498.27
39+
Rs. 492.27
49+
Rs. 486.27
74+
Rs. 480.26
99+
Rs. 450.25
199+
Rs. 444.24
249+
Rs. 438.24
499+
Rs. 432.24
999+
Rs. 420.23
Couldn't load pickup availability
Description
Description
Zinc Plated Steel Hi-Grip Wing Screw: Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse.
- Brand / Quality:
- JCS - High Quality
- Width:
- 13mm
- Min Adjustment Range:
- 22mm
- Max Adjustment Range:
- 30mm
Technical
Technical
| BS No. | 30 |
|---|---|
| Adjustment Range (mm) | 22-30mm |
| Adjustment Range (inch) | 7/8 - 1-1/8 inch |
| A | 8mm |
| B | 32mm |
| C | 12mm |
| D | 15mm |
| E | 13mm |
| F | 0.9mm |
| G | 24mm |
| Recommended Torque Nm | 5Nm |
| Recommended Torque lb-in | 45lb-in |
