SKU: WSZC22-JCS
JCS WSZC22 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 14-22mm Band Width 13mm
JCS WSZC22 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 14-22mm Band Width 13mm
Regular price
Rs. 591.45
Regular price
Sale price
Rs. 591.45
Taxes included.
In stock
Price Break
10+
Rs. 526.39
19+
Rs. 496.82
29+
Rs. 490.90
39+
Rs. 484.99
49+
Rs. 479.07
74+
Rs. 473.16
99+
Rs. 443.59
199+
Rs. 437.67
249+
Rs. 431.76
499+
Rs. 425.84
999+
Rs. 414.02
Description
Description
Zinc Plated Steel Hi-Grip Wing Screw: Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse.
- Brand / Quality:
- JCS - High Quality
- Width:
- 13mm
- Min Adjustment Range:
- 14mm
- Max Adjustment Range:
- 22mm
Technical
Technical
| BS No. | 22 |
|---|---|
| Adjustment Range (mm) | 14-22mm |
| Adjustment Range (inch) | 5/8 - 7/8 inch |
| A | 8mm |
| B | 32mm |
| C | 12mm |
| D | 15mm |
| E | 13mm |
| F | 0.9mm |
| G | 24mm |
| Recommended Torque Nm | 5Nm |
| Recommended Torque lb-in | 45lb-in |
