SKU: WSZC20-JCS
JCS WSZC20 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 13-20mm Band Width 9mm
JCS WSZC20 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 13-20mm Band Width 9mm
Regular price
Rs. 574.19
ex VAT
Regular price
Sale price
Rs. 574.19
ex VAT
In stock
Price Break
10+
Rs. 511.03
19+
Rs. 482.32
29+
Rs. 476.58
39+
Rs. 470.84
49+
Rs. 465.09
74+
Rs. 459.35
99+
Rs. 430.64
199+
Rs. 424.90
249+
Rs. 419.16
499+
Rs. 413.42
999+
Rs. 401.93
Couldn't load pickup availability
Description
Description
Zinc Plated Steel Hi-Grip Wing Screw: Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse.
- Brand / Quality:
- JCS - High Quality
- Width:
- 9mm
- Min Adjustment Range:
- 13mm
- Max Adjustment Range:
- 20mm
Technical
Technical
| BS No. | 20 |
|---|---|
| Adjustment Range (mm) | 13-20mm |
| Adjustment Range (inch) | 1/2 - 3/4 inch |
| A | 8mm |
| B | 31mm |
| C | 10mm |
| D | 12mm |
| E | 9mm |
| F | 0.7mm |
| G | 24mm |
| Recommended Torque Nm | 3Nm |
| Recommended Torque lb-in | 26lb-in |
