SKU: WS012-JUB
WS012 Zinc Plated Steel Jubilee Wingspade Clip Adjustment Range 9.5mm-12mm Band Width 9.9mm
WS012 Zinc Plated Steel Jubilee Wingspade Clip Adjustment Range 9.5mm-12mm Band Width 9.9mm
Regular price
Rs. 427.58
Regular price
Sale price
Rs. 427.58
Taxes included.
Low stock
Price Break
5+
Rs. 299.31
10+
Rs. 256.55
20+
Rs. 235.17
50+
Rs. 213.79
100+
Rs. 171.03
500+
Rs. 149.65
1000+
Rs. 128.27
Description
Description
Zinc Plated Steel Jubilee Wingspade Clips: Jubilee Wingspade® Clips have a thumb screw for fitting easily by hand. Suitable where repeated tightening/loosening/removing of the clip are required such as garden hoses and other domestic applications.
Benefits: Easy to fit by hand using thumb and forefinger.
- Brand / Quality:
- Jubilee - High Quality
- Width:
- 9.9mm
- Min Adjustment Range:
- 9.5mm
- Max Adjustment Range:
- 12mm
Technical
Technical
| Adjustment Range | 9.5mm - 12mm |
|---|---|
| Band Width (+/- 0.1) | 9.9mm |
| Band Thickness (+/- 0.1) | 0.762mm |
| Recommended Torque | 3.4Nm |
| Maximum Torque | 4.5Nm |
| Maximum Pressure | 182 Psi |
