SKU: UKC317H-SNR
SNR UKC317H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 75mm Bore Insert 64mm Outside Dia - Allow 2-3 Days
SNR UKC317H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 75mm Bore Insert 64mm Outside Dia - Allow 2-3 Days
Regular price
Rs. 63,823.76
Regular price
Sale price
Rs. 63,823.76
Taxes included.
In stock
Price Break
5+
Rs. 63,185.52
10+
Rs. 60,632.57
20+
Rs. 59,356.10
50+
Rs. 57,441.38
100+
Rs. 56,164.91
500+
Rs. 52,973.72
1000+
Rs. 44,676.63
Description
Description
UKC Series (Medium Duty) Cartridge Bearing Unit with Adaptor Sleeve Mounted: Cast iron cartridge bearing unit supplied with a full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. Cartridge units allow a self aligning bearing inserts to be used where a fixed bearing would normally be used.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, full width insert
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 75mm
- Style:
- UKC
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 75mm |
| A | 64mm |
| A3 | 3mm |
| B1 | 82mm |
| d1 | 110mm |
| H | 215mm |
| s1 | 48mm |
| G | M10x1 |
| --- | Load rating |
| Dynamic load C | 132.6 kN |
| Static load C0 | 96.5 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Mass | 11.41 kg |
