SKU: UCPX.20-64
UCPX20-64 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 4 inch Bore Insert
UCPX20-64 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 4 inch Bore Insert
Regular price
Rs. 53,893.60
ex VAT
Regular price
Sale price
Rs. 53,893.60
ex VAT
In stock
Price Break
10+
Rs. 47,965.30
19+
Rs. 45,270.62
29+
Rs. 44,731.69
39+
Rs. 44,192.75
49+
Rs. 43,653.82
74+
Rs. 43,114.88
99+
Rs. 40,420.20
199+
Rs. 39,881.26
249+
Rs. 39,342.33
499+
Rs. 38,803.39
999+
Rs. 37,725.52
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 101.6mm = 4 inch
- Style:
- UCPX
- Bolt Hole Centres:
- 337mm
Technical
Technical
| d | 4 inch |
|---|---|
| h | 127mm |
| a | 432mm |
| e | 337mm |
| b | 121mm |
| s2 | 64mm |
| s1 | 33mm |
| g | 52mm |
| w | 245mm |
| B1 | 117.5mm |
| n | 49.2mm |
| Bolt Size | 27mm |
| Weight | 31.8 kg |
| Dynamic load | 13300 kgf |
| Static load | 10500 kgf |
