SKU: UCPX.20
UCPX20 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 100mm Bore Insert
UCPX20 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 100mm Bore Insert
Regular price
Rs. 51,995.29
ex VAT
Regular price
Sale price
Rs. 51,995.29
ex VAT
In stock
Price Break
10+
Rs. 46,275.81
19+
Rs. 43,676.04
29+
Rs. 43,156.09
39+
Rs. 42,636.14
49+
Rs. 42,116.18
74+
Rs. 41,596.23
99+
Rs. 38,996.47
199+
Rs. 38,476.51
249+
Rs. 37,956.56
499+
Rs. 37,436.61
999+
Rs. 36,396.70
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 100mm
- Style:
- UCPX
- Bolt Hole Centres:
- 337mm
Technical
Technical
| d | 100mm |
|---|---|
| h | 127mm |
| a | 432mm |
| e | 337mm |
| b | 121mm |
| s2 | 64mm |
| s1 | 33mm |
| g | 52mm |
| w | 245mm |
| B1 | 117.5mm |
| n | 49.2mm |
| Bolt Size | 27mm |
| Weight | 31.8 kg |
| Dynamic load | 13300 kgf |
| Static load | 10500 kgf |
