SKU: UCPX.17
UCPX17 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 85mm Bore Insert
UCPX17 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 85mm Bore Insert
Regular price
Rs. 36,897.43
ex VAT
Regular price
Sale price
Rs. 36,897.43
ex VAT
In stock
Price Break
10+
Rs. 32,838.71
19+
Rs. 30,993.84
29+
Rs. 30,624.87
39+
Rs. 30,255.89
49+
Rs. 29,886.92
74+
Rs. 29,517.94
99+
Rs. 27,673.07
199+
Rs. 27,304.10
249+
Rs. 26,935.12
499+
Rs. 26,566.15
999+
Rs. 25,828.20
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 85mm
- Style:
- UCPX
- Bolt Hole Centres:
- 283mm
Technical
Technical
| d | 85mm |
|---|---|
| h | 101.6mm |
| a | 381mm |
| e | 283mm |
| b | 111mm |
| s2 | 60mm |
| s1 | 27mm |
| g | 45mm |
| w | 200mm |
| B1 | 96mm |
| n | 39.7mm |
| Bolt Size | M22 |
| Weight | 16.5 kg |
| Dynamic load | 7550 kgf |
| Static load | 6170 kgf |
