SKU: UCPX.15
UCPX15 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 75mm Bore Insert
UCPX15 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 75mm Bore Insert
Regular price
Rs. 18,664.00
ex VAT
Regular price
Sale price
Rs. 18,664.00
ex VAT
In stock
Price Break
10+
Rs. 16,610.96
19+
Rs. 15,677.76
29+
Rs. 15,491.12
39+
Rs. 15,304.48
49+
Rs. 15,117.84
74+
Rs. 14,931.20
99+
Rs. 13,998.00
199+
Rs. 13,811.36
249+
Rs. 13,624.72
499+
Rs. 13,438.08
999+
Rs. 13,064.80
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 75mm
- Style:
- UCPX
- Bolt Hole Centres:
- 229mm
Technical
Technical
| d | 75mm |
|---|---|
| h | 88.9mm |
| a | 330mm |
| e | 229mm |
| b | 89mm |
| s2 | 51mm |
| s1 | 27mm |
| g | 35mm |
| w | 175mm |
| B1 | 82.6mm |
| n | 33.3mm |
| Bolt Size | M22 |
| Weight | 11.1 kg |
| Dynamic load | 5700 kgf |
| Static load | 4550 kgf |
