SKU: UCPX.14-44
UCPX14-44 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2-3/4 inch Bore Insert
UCPX14-44 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2-3/4 inch Bore Insert
Regular price
Rs. 15,420.78
ex VAT
Regular price
Sale price
Rs. 15,420.78
ex VAT
In stock
Price Break
10+
Rs. 13,724.49
19+
Rs. 12,953.46
29+
Rs. 12,799.25
39+
Rs. 12,645.04
49+
Rs. 12,490.83
74+
Rs. 12,336.62
99+
Rs. 11,565.59
199+
Rs. 11,411.38
249+
Rs. 11,257.17
499+
Rs. 11,102.96
999+
Rs. 10,794.55
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 69.85mm = 2.75 (2-3/4) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 229mm
Technical
Technical
| d | 2-3/4 inch |
|---|---|
| h | 88.9mm |
| a | 330mm |
| e | 229mm |
| b | 89mm |
| s2 | 51mm |
| s1 | 27mm |
| g | 35mm |
| w | 171mm |
| B1 | 77.8mm |
| n | 33.8mm |
| Bolt Size | M22 |
| Weight | 10.6 kg |
| Dynamic load | 5190 kgf |
| Static load | 4190 kgf |
