SKU: UCPX.12
UCPX12 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 60mm Bore Insert
UCPX12 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 60mm Bore Insert
Regular price
Rs. 10,210.87
ex VAT
Regular price
Sale price
Rs. 10,210.87
ex VAT
In stock
Price Break
10+
Rs. 9,087.67
19+
Rs. 8,577.13
29+
Rs. 8,475.02
39+
Rs. 8,372.91
49+
Rs. 8,270.80
74+
Rs. 8,168.70
99+
Rs. 7,658.15
199+
Rs. 7,556.04
249+
Rs. 7,453.94
499+
Rs. 7,351.83
999+
Rs. 7,147.61
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 60mm
- Style:
- UCPX
- Bolt Hole Centres:
- 203mm
Technical
Technical
| d | 60mm |
|---|---|
| h | 76.2mm |
| a | 286mm |
| e | 203mm |
| b | 83mm |
| s2 | 41mm |
| s1 | 25mm |
| g | 32mm |
| w | 152mm |
| B1 | 65.1mm |
| n | 25.4mm |
| Bolt Size | M20 |
| Weight | 7.4 kg |
| Dynamic load | 4480 kgf |
| Static load | 3470 kgf |
