SKU: UCPX.10-31
UCPX10-31 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-15/16 inch Bore Insert
UCPX10-31 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-15/16 inch Bore Insert
Regular price
Rs. 3,814.36
ex VAT
Regular price
Sale price
Rs. 3,814.36
ex VAT
In stock
Price Break
10+
Rs. 3,394.78
19+
Rs. 3,204.06
29+
Rs. 3,165.92
39+
Rs. 3,127.78
49+
Rs. 3,089.63
74+
Rs. 3,051.49
99+
Rs. 2,860.77
199+
Rs. 2,822.63
249+
Rs. 2,784.48
499+
Rs. 2,746.34
999+
Rs. 2,670.05
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 49.21mm = 1.937 (1-15/16) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 171mm
Technical
Technical
| d | 1-15/16 inch |
|---|---|
| h | 63.5mm |
| a | 241mm |
| e | 171mm |
| b | 73mm |
| s2 | 36mm |
| s1 | 20mm |
| g | 27mm |
| w | 126mm |
| B1 | 55.6mm |
| n | 22.2mm |
| Bolt Size | M16 |
| Weight | 4.4 kg |
| Dynamic load | 3400 kgf |
| Static load | 2550 kgf |
