Challenge / FK UCPX09-28 Imperial Cast Iron Two Bolt Pillow Block Housing with 1-3/4 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Challenge / FK UCPX09-28 Imperial Cast Iron Two Bolt Pillow Block Housing with 1-3/4 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Regular price
Rs. 10,896.96
Regular price
Sale price
Rs. 10,896.96
Taxes included.
Equivalent to: UCPX.09-28
In stock
Price Break
10+
Rs. 9,698.29
19+
Rs. 9,153.45
29+
Rs. 9,044.48
39+
Rs. 8,935.51
49+
Rs. 8,826.54
74+
Rs. 8,717.57
99+
Rs. 8,172.72
199+
Rs. 8,063.75
249+
Rs. 7,954.78
499+
Rs. 7,845.81
999+
Rs. 7,627.87
Description
Description
UCPX Cast Iron Two Bolt Pillow Block Housing: These medium-duty bearing units are fitted with a triple lip seal in a cast iron housing and includes a grease nipple to facilitate re-lubrication. These bearings are perfect for agricultural applications where the bearings are exposed to contamination. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: High tolerance to harsh environments, cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Equivalent: UCPX.09-28
- Brand / Quality:
- Challenge / FK - Good Quality
- Inside Diameter:
- 44.45mm = 1.75 (1-3/4) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 156mm
Technical
Technical
| Shaft Diameter d | 1-3/4 inch |
|---|---|
| Casting Centre Line Height h | 58.7mm |
| Casting Length a | 222mm |
| Recommended Bolt Centres l | 156mm |
| Casting Width b | 67mm |
| Slot Length s<sub>2</sub> | 33mm |
| Slot Width s<sub>1</sub> | 20mm |
| Foot Height g | 26mm |
| Overall Height w | 116mm |
| Bearing Insert Width Bi | 51.6mm |
| Back of Bearing to Centre Line n | 19mm |
| Bolt Size | 5/8 inch |
| Grub Screws x 2 | 5/16 - 24UNF inch |
| Load Rating (Dynamic) | 2750kg |
| Load Rating (Static) | 2020kg |
| Max Speed | 1900 rev/min |
| Working Temperature | -30°C to +120°C |
| Insert No | UCX09-28 |
| Housing No | PX09 |
