SKU: UCPX.09-26
UCPX09-26 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-5/8 inch Bore Insert
UCPX09-26 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-5/8 inch Bore Insert
Regular price
Rs. 2,195.91
ex VAT
Regular price
Sale price
Rs. 2,195.91
ex VAT
Equivalent to: MP1-5/8
In stock
Price Break
10+
Rs. 1,954.36
19+
Rs. 1,844.56
29+
Rs. 1,822.61
39+
Rs. 1,800.65
49+
Rs. 1,778.69
74+
Rs. 1,756.73
99+
Rs. 1,646.93
199+
Rs. 1,624.97
249+
Rs. 1,603.01
499+
Rs. 1,581.06
999+
Rs. 1,537.14
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Equivalent: MP1-5/8
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 41.28mm = 1.625 (1-5/8) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 156mm
Technical
Technical
| d | 1-5/8 inch |
|---|---|
| h | 58.7mm |
| a | 222mm |
| e | 156mm |
| b | 67mm |
| s2 | 33mm |
| s1 | 20mm |
| g | 26mm |
| w | 116mm |
| B1 | 61.6mm |
| n | 19mm |
| Bolt Size | M16 |
| Weight | 3.6 kg |
| Dynamic load | 2750 kgf |
| Static load | 2020 kgf |
