SKU: UCPX.06-19
UCPX06-19 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-3/16 inch Bore Insert
UCPX06-19 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-3/16 inch Bore Insert
Regular price
Rs. 1,800.80
ex VAT
Regular price
Sale price
Rs. 1,800.80
ex VAT
Equivalent to: MP1-3/16
In stock
Price Break
10+
Rs. 1,602.71
19+
Rs. 1,512.67
29+
Rs. 1,494.66
39+
Rs. 1,476.66
49+
Rs. 1,458.65
74+
Rs. 1,440.64
99+
Rs. 1,350.60
199+
Rs. 1,332.59
249+
Rs. 1,314.58
499+
Rs. 1,296.58
999+
Rs. 1,260.56
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Equivalent: MP1-3/16
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 30.16mm = 1.187 (1-3/16) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 127mm
Technical
Technical
| d | 1-3/16 inch |
|---|---|
| h | 47.6mm |
| a | 175mm |
| e | 127mm |
| b | 57mm |
| s2 | 25mm |
| s1 | 17mm |
| g | 20mm |
| w | 94mm |
| B1 | 42.9mm |
| n | 17.5mm |
| Bolt Size | M12 |
| Weight | 2 kg |
| Dynamic load | 2010 kgf |
| Static load | 1390 kgf |
| Rec max speed | 4500 rpm |
