SKU: UCP.209-26
UCP209-26 Imperial Cast Iron Two Bolt Pillow / Plummer Block Housing with 1-5/8 inch Bore Insert
UCP209-26 Imperial Cast Iron Two Bolt Pillow / Plummer Block Housing with 1-5/8 inch Bore Insert
Regular price
Rs. 3,506.62
ex VAT
Regular price
Sale price
Rs. 3,506.62
ex VAT
Equivalent to: NP45
In stock
Price Break
10+
Rs. 3,120.89
19+
Rs. 2,945.56
29+
Rs. 2,910.49
39+
Rs. 2,875.43
49+
Rs. 2,840.36
74+
Rs. 2,805.30
99+
Rs. 2,629.97
199+
Rs. 2,594.90
249+
Rs. 2,559.83
499+
Rs. 2,524.77
999+
Rs. 2,454.63
Couldn't load pickup availability
Description
Description
|
UCP or NP Series Plummer / Pillow Housings: Supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required. Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Equivalent: NP45
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 41.28mm = 1.625 (1-5/8) inch
- Style:
- UCP
- Bolt Hole Centres:
- 146mm
Technical
Technical
| d | 1-5/8 inch |
|---|---|
| h | 54mm |
| a | 190mm |
| e | 146mm |
| b | 54mm |
| s2 | 21mm |
| s1 | 17mm |
| g | 20mm |
| w | 106mm |
| B1 | 49.2mm |
| n | 19mm |
| Bolt Size | M14 |
| Weight | 2.2 kg |
| Dynamic load | 2560 kgf |
| Static load | 1810 kgf |
| Rec max speed | 3700 rpm |
