SKU: UCFL305D1-NTN
NTN UCFL305D1 Metric Two Bolt Oval Cast Iron Flange Housing with 25mm Bore Insert - Allow 2-3 Days
NTN UCFL305D1 Metric Two Bolt Oval Cast Iron Flange Housing with 25mm Bore Insert - Allow 2-3 Days
Regular price
Rs. 7,083.28
Regular price
Sale price
Rs. 7,083.28
Taxes included.
In stock
Price Break
5+
Rs. 7,012.45
10+
Rs. 6,729.12
20+
Rs. 6,587.45
50+
Rs. 6,374.95
100+
Rs. 6,233.29
500+
Rs. 5,879.12
1000+
Rs. 4,958.30
Description
Description
UCFL300 Series Heavy Duty 2 Bolt Oval Housings: These heavy-duty bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts can be removed from the housing for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 25mm
- Style:
- UCFL
- Bolt Hole Centres:
- 113mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 25mm |
| H | 150mm |
| J | 113mm |
| A<sub>2</sub> | 16mm |
| A<sub>1</sub> | 13mm |
| A | 29mm |
| N | 19mm |
| L | 80mm |
| A<sub>0</sub> | 39mm |
| B | 38mm |
| S | 15mm |
| Fixing bolt | M16 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 23.5 kN |
| Static load C<sub>0r</sub> | 10.9 kN |
| Fatigue load limit C<sub>u</sub> | 0.855 kN |
| --- | Unit information |
| Mass | 0.9 kg |
