SKU: UCFG212D1-NTN
NTN UCFG212D1 Metric Four Bolt Square Steel Flange Housing with 60mm Bore Insert - Allow 2-3 Days
NTN UCFG212D1 Metric Four Bolt Square Steel Flange Housing with 60mm Bore Insert - Allow 2-3 Days
Regular price
Rs. 56,728.96
Regular price
Sale price
Rs. 56,728.96
Taxes included.
In stock
Price Break
5+
Rs. 56,161.67
10+
Rs. 53,892.51
20+
Rs. 52,757.93
50+
Rs. 51,056.06
100+
Rs. 49,921.48
500+
Rs. 47,085.04
1000+
Rs. 39,710.27
Description
Description
UCFG Series 4 Bolt Square Steel Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the cast iron housing and include a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement if required.
Benefits: Cost-effective bearing/housing assembly, can be re-lubricated, replaceable insert, grub screw fixing
Benefits: Cost-effective bearing/housing assembly, can be re-lubricated, replaceable insert, grub screw fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 60mm
- Style:
- UCFG
- Bolt Hole Centres:
- 143mm
Technical
Technical
| Shaft diameter | 60mm |
|---|---|
| L | 175mm |
| J | 143mm |
| A<sub>2</sub> | 29mm |
| A<sub>1</sub> | 18mm |
| A | 48mm |
| N | 19mm |
| A<sub>0</sub> | 68.7mm |
| B | 65.1mm |
| S | 25.4mm |
| Fixing bolt | M16 |
| Mass | 5.7 kg |
