SKU: UCFE212-39-SNR
SNR UCFE212-39 Imperial Four Bolt Square Cast Iron Flange Housing with 2-7/16 inch Bore Insert - Allow 2-3 Days
SNR UCFE212-39 Imperial Four Bolt Square Cast Iron Flange Housing with 2-7/16 inch Bore Insert - Allow 2-3 Days
Regular price
Rs. 7,917.96
Regular price
Sale price
Rs. 7,917.96
Taxes included.
In stock
Price Break
10+
Rs. 7,046.98
19+
Rs. 6,651.09
29+
Rs. 6,571.91
39+
Rs. 6,492.73
49+
Rs. 6,413.55
74+
Rs. 6,334.37
99+
Rs. 5,938.47
199+
Rs. 5,859.29
249+
Rs. 5,780.11
499+
Rs. 5,700.93
999+
Rs. 5,542.57
Description
Description
UCFE/UCFEX Series 4 Bolt Cast Iron Square Flange Housing: These cast iron housing units include a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: High tolerance to harsh environments, cost-effective bearing/housing assembly, re-lubricatable, replaceable insert, grub screw fixing
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 61.91mm = 2.437 (2-7/16) inch
- Style:
- UCFE
- Bolt Hole Centres:
- 143mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 2-7/16 inch |
| A | 53.5mm |
| A1 | 16mm |
| A2 | 73.7mm |
| B | 65.1mm |
| e | 34mm |
| J | 143mm |
| L | 175mm |
| N | 18mm |
| S | 25.4mm |
| G | R1/8″ |
| --- | Load rating |
| Dynamic load C | 52.5 kN |
| Static load C0 | 32.8 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 16.8 Nm |
| Mass | 4.78 kg |
