SKU: UCFE211-SNR
SNR UCFE211 Metric Four Bolt Square Cast Iron Flange Housing with 55mm Bore Insert - Allow 2-3 Days
SNR UCFE211 Metric Four Bolt Square Cast Iron Flange Housing with 55mm Bore Insert - Allow 2-3 Days
Regular price
Rs. 6,910.45
Regular price
Sale price
Rs. 6,910.45
Taxes included.
In stock
Price Break
10+
Rs. 6,150.30
19+
Rs. 5,804.78
29+
Rs. 5,735.67
39+
Rs. 5,666.57
49+
Rs. 5,597.46
74+
Rs. 5,528.36
99+
Rs. 5,182.84
199+
Rs. 5,113.73
249+
Rs. 5,044.63
499+
Rs. 4,975.52
999+
Rs. 4,837.32
Description
Description
UCFE/UCFEX Series 4 Bolt Cast Iron Square Flange Housing: These cast iron housing units include a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: High tolerance to harsh environments, cost-effective bearing/housing assembly, re-lubricatable, replaceable insert, grub screw fixing
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 55mm
- Style:
- UCFE
- Bolt Hole Centres:
- 130mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 55mm |
| A | 48.5mm |
| A1 | 15mm |
| A2 | 64.4mm |
| B | 55.6mm |
| e | 31mm |
| J | 130mm |
| L | 162mm |
| N | 18mm |
| S | 22.2mm |
| G | R1/8″ |
| --- | Load rating |
| Dynamic load C | 43.55 kN |
| Static load C0 | 29.2 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 22 Nm |
| Mass | 3.66 kg |
