SKU: UCFCX09D1-NTN
NTN UCFCX09D1 Metric Four Bolt Cast Iron Round Flanged Housing with 45mm Insert - Allow 2-3 Days
NTN UCFCX09D1 Metric Four Bolt Cast Iron Round Flanged Housing with 45mm Insert - Allow 2-3 Days
Regular price
Rs. 6,863.09
Regular price
Sale price
Rs. 6,863.09
Taxes included.
In stock
Price Break
10+
Rs. 6,108.15
19+
Rs. 5,765.00
29+
Rs. 5,696.36
39+
Rs. 5,627.73
49+
Rs. 5,559.10
74+
Rs. 5,490.47
99+
Rs. 5,147.32
199+
Rs. 5,078.69
249+
Rs. 5,010.06
499+
Rs. 4,941.42
999+
Rs. 4,804.16
Description
Description
UCFCX Series Medium Duty 4 Bolt Round Housings: These medium-duty bearing units are supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 45mm
- Style:
- UCFCX
- Pitch Circle Diameter:
- 91.9mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 45mm |
| L | 155mm |
| J | 130mm |
| (J<sub>1</sub>) | 91.9mm |
| A<sub>2</sub> | 8mm |
| N | 14mm |
| A<sub>3</sub> | 12mm |
| A<sub>1</sub> | 25mm |
| A | 37mm |
| H<sub>3</sub> | 108mm |
| A<sub>0</sub> | 52.6mm |
| B | 51.6mm |
| S | 19mm |
| F (Min.) | 68mm |
| Fixing bolt | M12 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 39 kN |
| Static load C<sub>0r</sub> | 23.2 kN |
| Fatigue load limit C<sub>u</sub> | 1.82 kN |
| --- | Unit information |
| Mass | 2.6 kg |
