SKU: UCFC.210-31
UCFC210-31 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-15/16 inch Insert
UCFC210-31 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-15/16 inch Insert
Regular price
Rs. 4,516.50
Regular price
Sale price
Rs. 4,516.50
Taxes included.
In stock
Price Break
10+
Rs. 4,019.69
19+
Rs. 3,793.86
29+
Rs. 3,748.70
39+
Rs. 3,703.53
49+
Rs. 3,658.37
74+
Rs. 3,613.20
99+
Rs. 3,387.38
199+
Rs. 3,342.21
249+
Rs. 3,297.05
499+
Rs. 3,251.88
999+
Rs. 3,161.55
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 49.21mm = 1.937 (1-15/16) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 138.11mm = 138.11 (5-7/16) inch
Technical
Technical
| d | 1-15/16 inch |
|---|---|
| a | 6-1/2 inch |
| P | 5-7/16 inch |
| e | 3-27/32 inch |
| i | 25/64 inch |
| L | 1-9/16 inch |
| s | 5/8 inch |
| j | 15/32 inch |
| k | 9/16 inch |
| g | 1-3/32 inch |
| f | 4.3307 inch |
| z | 2.0315 inch |
| Bi | 1-11/16 inch |
| n | 0.7480 inch |
| Bolt Size | 1/2 inch |
| Weight | 3 kg |
| Dynamic load | 2750 kgf |
| Static load | 2020 kgf |
