SKU: UCFC.208-25
UCFC208-25 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-9/16 inch Insert
UCFC208-25 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-9/16 inch Insert
Regular price
Rs. 1,738.75
ex VAT
Regular price
Sale price
Rs. 1,738.75
ex VAT
In stock
Price Break
10+
Rs. 1,547.49
19+
Rs. 1,460.55
29+
Rs. 1,443.16
39+
Rs. 1,425.78
49+
Rs. 1,408.39
74+
Rs. 1,391.00
99+
Rs. 1,304.06
199+
Rs. 1,286.68
249+
Rs. 1,269.29
499+
Rs. 1,251.90
999+
Rs. 1,217.13
Couldn't load pickup availability
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 39.69mm = 1.563 (1-9/16) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 119.86mm = 119.86 (4-23/32) inch
Technical
Technical
| d | 1-9/16 inch |
|---|---|
| a | 5-23/32 inch |
| P | 4-23/32 inch |
| e | 3-11/32 inch |
| i | 7/16 inch |
| L | 1-27/64 inch |
| s | 35/64 inch |
| j | 25/64 inch |
| k | 11/32 inch |
| g | 1-1/32 inch |
| f | 3.9370 inch |
| z | 1-5/8 inch |
| Bi | 1.9370 inch |
| n | 0.7480 inch |
| Bolt Size | 7/16 inch |
| Weight | 2 kg |
| Dynamic load | 2560 kgf |
| Static load | 1810 kgf |
