UCFC207-21 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-5/16 inch Insert
UCFC207-21 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-5/16 inch Insert
Regular price
Rs. 2,639.75
Regular price
Sale price
Rs. 2,639.75
Taxes included.
In stock
Price Break
10+
Rs. 2,349.38
19+
Rs. 2,217.39
29+
Rs. 2,190.99
39+
Rs. 2,164.60
49+
Rs. 2,138.20
74+
Rs. 2,111.80
99+
Rs. 1,979.81
199+
Rs. 1,953.42
249+
Rs. 1,927.02
499+
Rs. 1,900.62
999+
Rs. 1,847.83
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 33.33mm = 1.312 (1-5/16) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 109.93mm = 109.93 (4-21/64) inch
Technical
Technical
| d | 1-5/16 inch |
|---|---|
| a | 5-5/16 inch |
| P | 4-21/64 inch |
| e | 3-1/16 inch |
| i | 7/16 inch |
| L | 1-11/32 inch |
| s | 35/64 inch |
| j | 5/16 inch |
| k | 11/32 inch |
| g | 1-1/32 inch |
| f | 3.5433 inch |
| z | 1-7/16 inch |
| Bi | 1.6890 inch |
| n | 0.6890 inch |
| Bolt Size | 7/16 inch |
| Weight | 1.7 kg |
| Dynamic load | 2010 kgf |
| Static load | 1390 kgf |
