SKU: UCC319-SNR
SNR UCC319 Metric Cast Iron Cartridge Unit with 95mm Bore Insert 72mm Outside Dia - Allow 2-3 Days
SNR UCC319 Metric Cast Iron Cartridge Unit with 95mm Bore Insert 72mm Outside Dia - Allow 2-3 Days
Regular price
Rs. 63,864.72
Regular price
Sale price
Rs. 63,864.72
Taxes included.
In stock
Price Break
5+
Rs. 63,226.07
10+
Rs. 60,671.48
20+
Rs. 59,394.19
50+
Rs. 57,478.25
100+
Rs. 56,200.95
500+
Rs. 53,007.72
1000+
Rs. 44,705.30
Description
Description
UCC Series (Normal Duty) Cartridge Bearing Unit: Cast iron cartridge bearing unit supplied with a full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. Cartridge units allow a self aligning bearing inserts to be used where a fixed bearing would normally be used.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, full width insert
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 95mm
- Style:
- UCC
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 95mm |
| A | 72mm |
| A3 | 3mm |
| B | 103mm |
| H | 240mm |
| S | 41mm |
| G | M10x1 |
| --- | Load rating |
| Dynamic load C | 156 kN |
| Static load C0 | 122 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Mass | 15.91 kg |
