SKU: UCC314-SNR
SNR UCC314 Metric Cast Iron Cartridge Unit with 70mm Bore Insert 52mm Outside Dia - Allow 2-3 Days
SNR UCC314 Metric Cast Iron Cartridge Unit with 70mm Bore Insert 52mm Outside Dia - Allow 2-3 Days
Regular price
Rs. 28,388.16
Regular price
Sale price
Rs. 28,388.16
Taxes included.
In stock
Price Break
5+
Rs. 28,104.28
10+
Rs. 26,968.75
20+
Rs. 26,400.99
50+
Rs. 25,549.34
100+
Rs. 24,981.58
500+
Rs. 23,562.17
1000+
Rs. 19,871.71
Description
Description
UCC Series (Normal Duty) Cartridge Bearing Unit: Cast iron cartridge bearing unit supplied with a full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. Cartridge units allow a self aligning bearing inserts to be used where a fixed bearing would normally be used.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, full width insert
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 70mm
- Style:
- UCC
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 70mm |
| A | 52mm |
| A3 | 2.5mm |
| B | 78mm |
| H | 180mm |
| S | 33mm |
| G | M10x1 |
| --- | Load rating |
| Dynamic load C | 104.26 kN |
| Static load C0 | 68 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Mass | 6.75 kg |
