SKU: UCC206-19
UCC206-19 Imperial Cast Iron Normal Duty Cartridge Unit with 1-3/8 inch Bore Insert 3.3465 inch Outside Dia
UCC206-19 Imperial Cast Iron Normal Duty Cartridge Unit with 1-3/8 inch Bore Insert 3.3465 inch Outside Dia
Regular price
Rs. 2,870.18
Regular price
Sale price
Rs. 2,870.18
Taxes included.
In stock
Price Break
10+
Rs. 2,554.46
19+
Rs. 2,410.95
29+
Rs. 2,382.25
39+
Rs. 2,353.55
49+
Rs. 2,324.85
74+
Rs. 2,296.14
99+
Rs. 2,152.64
199+
Rs. 2,123.93
249+
Rs. 2,095.23
499+
Rs. 2,066.53
999+
Rs. 2,009.13
Description
Description
UCC Series (Normal Duty) Cartridge Bearing Unit: Cast iron cartridge bearing unit supplied with a full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. Cartridge units allow a self aligning bearing inserts to be used where a fixed bearing would normally be used.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, full width insert
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 34.93mm = 1.375 (1-3/8) inch
- Outside Diameter:
- 85.001mm = 3.3465 inch
- Style:
- UCC
Technical
Technical
| Bore d | 1-3/8 inch |
|---|---|
| Outer Dia a | 3.3465 inch |
| g | 1-1/16 inch |
| r | 0.079 inch |
| B | 1.500 inch |
| n | 0.626 inch |
| Bearing No | UC206-19 |
| Housing No | C206 |
