SKU: UC.208-25
UC208-25 Imperial Bearing Insert with 1-9/16 inch Bore 80mm Outside Dia
UC208-25 Imperial Bearing Insert with 1-9/16 inch Bore 80mm Outside Dia
Regular price
Rs. 1,447.48
ex VAT
Regular price
Sale price
Rs. 1,447.48
ex VAT
In stock
Price Break
10+
Rs. 1,288.26
19+
Rs. 1,215.88
29+
Rs. 1,201.41
39+
Rs. 1,186.93
49+
Rs. 1,172.46
74+
Rs. 1,157.98
99+
Rs. 1,085.61
199+
Rs. 1,071.14
249+
Rs. 1,056.66
499+
Rs. 1,042.19
999+
Rs. 1,013.24
Couldn't load pickup availability
Description
Description
|
UC or 10 -- G Series: Normal duty bearing insert with 2 grub screws to allow tightening against the shaft once fitted.
These inserts are ideal replacements for housed types which can easily be removed from the housings when replacement is required |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 39.69mm = 1.563 (1-9/16) inch
- Outside Diameter:
- 80mm
- Style:
- UC
- Type:
- Spherical Outer
Technical
Technical
| d | 1-9/16 inch |
|---|---|
| D | 80mm |
| Bi | 49.2mm |
| Be | 21mm |
| n | 19mm |
| m | 30.2mm |
| G | 8mm |
| Grub screw | 5/16"-24 UNF |
| Weight | 0.65 kg |
| Dynamic load | 2560 kgf |
| Static load | 1810 kgf |
