SKU: UC.204-12.TS.CHAL
Challenge UC204-12 Imperial Insert with Grub Screws with 3/4 inch Bore 47mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Challenge UC204-12 Imperial Insert with Grub Screws with 3/4 inch Bore 47mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Regular price
Rs. 1,528.54
Regular price
Sale price
Rs. 1,528.54
Taxes included.
Equivalent to: UC.204-12
In stock
Price Break
10+
Rs. 1,360.40
19+
Rs. 1,283.97
29+
Rs. 1,268.69
39+
Rs. 1,253.40
49+
Rs. 1,238.12
74+
Rs. 1,222.83
99+
Rs. 1,146.41
199+
Rs. 1,131.12
249+
Rs. 1,115.83
499+
Rs. 1,100.55
999+
Rs. 1,069.98
Description
Description
UC Insert with Grub Screws: These normal-duty bearing units are fitted with a triple lip seal. These bearings are perfect for agricultural applications where the bearings are exposed to contamination. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. Also available as a complete housing assembly.
Benefits: High tolerance to harsh environments, cost effective bearing, re-lubricatable, grub screw fixing
Equivalent: UC.204-12
- Brand / Quality:
- Challenge - Good Quality
- Inside Diameter:
- 19.05mm = 0.75 (3/4) inch
- Style:
- UC
Technical
Technical
| Shaft Diameter d | 3/4 inch |
|---|---|
| Outside Diameter D | 47mm |
| Overall Width Bi | 31mm |
| Inner Race Width Be | 17mm |
| Back of Bearing to Centre Line n | 12.7mm |
| Front of Bearing to Centre Line m | 18.3mm |
| Dimension G | 5mm |
| Grub Screws x 2 | 1/4 - 28UNF inch |
| Load Rating (Dynamic) | 1000kg |
| Load Rating (Static) | 630kg |
| Max Speed | 4000 rev/min |
| Grease Nipple Thread Size | M6 |
| Working Temperature | -30°C to +120°C |
