SKU: TU1.15/16TF-SKF
SKF TU1-15/16TF Grub Screw Type Take Up Unit 1-15/16 inch Bore
SKF TU1-15/16TF Grub Screw Type Take Up Unit 1-15/16 inch Bore
Regular price
Rs. 18,002.00
Regular price
Sale price
Rs. 18,002.00
Taxes included.
In stock
Price Break
10+
Rs. 16,021.78
19+
Rs. 15,121.68
29+
Rs. 14,941.66
39+
Rs. 14,761.64
49+
Rs. 14,581.62
74+
Rs. 14,401.60
99+
Rs. 13,501.50
199+
Rs. 13,321.48
249+
Rs. 13,141.46
499+
Rs. 12,961.44
999+
Rs. 12,601.40
Description
Description
|
SKF Y-bearing Take-Up Units with Cast Housing and Grub Screws: This unit consists of a cast housing and an insert bearing. They are typically mounted in take-up frames and connected by an adjustment screw. A grease fitting is provided in the housing for re-lubrication. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 49.21mm = 1.937 (1-15/16) inch
- Style:
- TU
Technical
Technical
| d | 1-15/16 inch |
|---|---|
| A | 49mm |
| A1 | 17.5mm |
| A2 | 36mm |
| B | 51.6mm |
| D1 | 29mm |
| H | 117mm |
| H1 | 101mm |
| H2 | 83mm |
| L | 149mm |
| L1 | 90mm |
| L2 | 16mm |
| L3 | 86mm |
| N | 49mm |
| N1 | 19mm |
| s1 | 32.6mm |
| Static load Cr | 23.2 kN |
| Dynamic load Cor | 35.1 kN |
| Fatigue load limit Pu | 0.98 kN |
| Limiting speed | 4000 rpm |
| Weight | 2.4 kg |
