SKU: TMHP50/320-SKF
SKF TMHP50/320 Hydraulically Assisted Heavy Duty Jaw Pullers 310-506mm / 12.2-19.9 in
SKF TMHP50/320 Hydraulically Assisted Heavy Duty Jaw Pullers 310-506mm / 12.2-19.9 in
Regular price
Rs. 1,088,062.23
Regular price
Sale price
Rs. 1,088,062.23
Taxes included.
In stock
Price Break
10+
Rs. 968,375.38
19+
Rs. 913,972.27
29+
Rs. 903,091.65
39+
Rs. 892,211.03
49+
Rs. 881,330.41
74+
Rs. 870,449.78
99+
Rs. 816,046.67
199+
Rs. 805,166.05
249+
Rs. 794,285.43
499+
Rs. 783,404.81
999+
Rs. 761,643.56
Description
Description
|
SKF Hydraulically Assisted Heavy Duty Jaw Pullers TMHP Series: The SKF hydraulically-assisted pullers TMHP 15, TMHP 30 and TMHP 50 provide new combined forces of puller power and safety. They are self-centring pullers for the occasions when large forces are inevitable. Pantograph system for ultimate alignment of withdrawal forces and minimised risk of damaging shaft or bearing. Benefits: Extreme forces applied with ease (self-centring, lifting handle, eye bolt, etc.) |
- Brand / Quality:
- SKF - High Quality
Technical
Technical
| Width of Grip | 310-506mm (12.2-19.9 in.) |
|---|---|
| Effective Length of Arms | 320mm (12.6 in.) |
| Claw Height | 40mm (1.6 in.) |
| Stroke | 40mm (1.6 in.) |
| Maximum Working Pressure Hydraulic Cylinder | 80 Mpa (11 600 psi) |
| Maximum Withdrawal Force | 500 kN (56 US ton) |
