SKU: TMHP30/170-SKF
SKF TMHP Hydraulically Assisted Heavy Duty Jaw Pullers 290-500mm / 11.4-19.7in
SKF TMHP Hydraulically Assisted Heavy Duty Jaw Pullers 290-500mm / 11.4-19.7in
Regular price
Rs. 913,640.43
ex VAT
Regular price
Sale price
Rs. 913,640.43
ex VAT
In stock
Price Break
10+
Rs. 813,139.98
19+
Rs. 767,457.96
29+
Rs. 758,321.56
39+
Rs. 749,185.15
49+
Rs. 740,048.75
74+
Rs. 730,912.34
99+
Rs. 685,230.32
199+
Rs. 676,093.92
249+
Rs. 666,957.51
499+
Rs. 657,821.11
999+
Rs. 639,548.30
Couldn't load pickup availability
Description
Description
|
SKF Hydraulically Assisted Heavy Duty Jaw Pullers TMHP Series: The SKF hydraulically-assisted pullers TMHP 15, TMHP 30 and TMHP 50 provide new combined forces of puller power and safety. They are self-centring pullers for the occasions when large forces are inevitable. Pantograph system for ultimate alignment of withdrawal forces and minimised risk of damaging shaft or bearing. Benefits: Extreme forces applied with ease (self-centring, lifting handle, eye bolt, etc.) |
- Brand / Quality:
- SKF - High Quality
Technical
Technical
| Width of Grip | 290-500mm (11.4-19.7 in.) |
|---|---|
| Effective Length of Arms | 170mm (6.7 in.) |
| Claw Height | 35mm (1.4 in.) |
| Stroke | 50mm (2 in.) |
| Maximum Working Pressure Hydraulic Cylinder | 80 Mpa (11 600 psi) |
| Maximum Withdrawal Force | 300 kN (34 US ton) |
