SKF TMHP Hydraulically Assisted Heavy Duty Jaw Pullers 195-386mm / 7.7-15.2in
SKF TMHP Hydraulically Assisted Heavy Duty Jaw Pullers 195-386mm / 7.7-15.2in
Regular price
Rs. 666,897.18
ex VAT
Regular price
Sale price
Rs. 666,897.18
ex VAT
In stock
Price Break
10+
Rs. 593,538.49
19+
Rs. 560,193.63
29+
Rs. 553,524.66
39+
Rs. 546,855.69
49+
Rs. 540,186.72
74+
Rs. 533,517.74
99+
Rs. 500,172.89
199+
Rs. 493,503.91
249+
Rs. 486,834.94
499+
Rs. 480,165.97
999+
Rs. 466,828.03
Couldn't load pickup availability
Description
Description
|
SKF Hydraulically Assisted Heavy Duty Jaw Pullers TMHP Series: The SKF hydraulically-assisted pullers TMHP 15, TMHP 30 and TMHP 50 provide new combined forces of puller power and safety. They are self-centring pullers for the occasions when large forces are inevitable. Pantograph system for ultimate alignment of withdrawal forces and minimised risk of damaging shaft or bearing. Benefits: Extreme forces applied with ease (self-centring, lifting handle, eye bolt, etc.) |
- Brand / Quality:
- SKF - High Quality
Technical
Technical
| Width of Grip | 195-386mm (7.7-15.2 in.) |
|---|---|
| Effective Length of Arms | 264mm (10.4 in.) |
| Claw Height | 30mm (1.2 in.) |
| Stroke | 100mm (3.9 in.) |
| Maximum Working Pressure Hydraulic Cylinder | 80 Mpa (11 600 psi) |
| Maximum Withdrawal Force | 150 kN (17 US ton) |
