SKU: SUCNFL208FG1-SNR
SNR SUCNFL208FG1 Metric Sentinel Thermoplastic Four Bolt Square Flanged Bracket Housing Unit with40mm Bore Insert - Allow 2-3 Days
SNR SUCNFL208FG1 Metric Sentinel Thermoplastic Four Bolt Square Flanged Bracket Housing Unit with40mm Bore Insert - Allow 2-3 Days
Regular price
Rs. 25,533.34
Regular price
Sale price
Rs. 25,533.34
Taxes included.
In stock
Price Break
5+
Rs. 25,278.01
10+
Rs. 24,256.67
20+
Rs. 23,746.01
50+
Rs. 22,980.01
100+
Rs. 22,469.34
500+
Rs. 21,192.67
1000+
Rs. 17,873.34
Description
Description
SNR MUCNFL200 Sentinel Two Bolt Oval Thermoplastic Housing Unit: This housing is designed for durability in demanding environments. With a sturdy thermoplastic housing and a stainless steel insert ball bearing secured by socket set screws, this unit ensures reliable performance. Its innovative seal with slinger protects against contaminants, while the LUBSOLID food-grade lubricant makes it ideal for food processing applications. Experience exceptional strength and reliability with this versatile housing unit.
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 40mm
- Temperature Range:
- -10 to 80 deg C
- Style:
- SUCNFL
- Colour:
- White
- Bolt Hole Centres:
- 144.0mm
Technical
Technical
| Bore | 40mm |
|---|---|
| A - Housing height | 37.5mm |
| A1 - Housing foot height / flange height | 20mm |
| A2 - Total height from mounting surface | 51.7mm |
| B - Width of Inner Ring | 49.2mm |
| d - Shaft diameter | 40mm |
| e - Distance mounting surface to bearing centre | 21.5mm |
| H - Housing length, width or diameter | 175mm |
| J - Mounting holes distance | 144mm |
| L - Housing width / diameter | 100mm |
| N - Mounting hole dimension | 14mm |
| S - Distance front side/bearing centre | 19mm |
| C - Dynamic load rating | 32 kN |
| C0 - Static load rating | 19.3 kN |
| Operating temperature min. | -10 Deg C |
| Operating temperature max. | 80 Deg C |
| Mass | 0.81kg |
| Recommended tightening torque for set screw | 8.3 Nm |
