SKU: SSUCF.209
SSUCF209 Metric Four Bolt Square Stainless Steel Flange Housing with 45mm Bore Stainless Insert
SSUCF209 Metric Four Bolt Square Stainless Steel Flange Housing with 45mm Bore Stainless Insert
Regular price
Rs. 9,367.13
Regular price
Sale price
Rs. 9,367.13
Taxes included.
In stock
Price Break
10+
Rs. 8,336.75
19+
Rs. 7,868.39
29+
Rs. 7,774.72
39+
Rs. 7,681.05
49+
Rs. 7,587.38
74+
Rs. 7,493.70
99+
Rs. 7,025.35
199+
Rs. 6,931.68
249+
Rs. 6,838.00
499+
Rs. 6,744.33
999+
Rs. 6,556.99
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 45mm
- Style:
- SSUCF
- Bolt Hole Centres:
- 105mm
Technical
Technical
| d | 45mm |
|---|---|
| a | 137mm |
| e | 105mm |
| i | 22mm |
| g | 18mm |
| L | 38mm |
| S | 16mm |
| Z | 52.2mm |
| Bi | 49.2mm |
| n | 19mm |
| Bolt | 14mm |
| Weight | 2.3 kg |
| Dynamic load | 2560 kgf |
| Static load | 1810 kgf |
