SKU: SLG205_IMP_NAK
NAK SLG205 Hardened Stainless Sleeve for Shafts 4.183-4.191 inch - Allow 7-10 Days
NAK SLG205 Hardened Stainless Sleeve for Shafts 4.183-4.191 inch - Allow 7-10 Days
Regular price
Rs. 5,392.02
ex VAT
Regular price
Sale price
Rs. 5,392.02
ex VAT
Allow 7-10 Days
In stock
Price Break
5+
Rs. 5,338.10
10+
Rs. 5,122.42
20+
Rs. 5,014.58
50+
Rs. 4,852.82
100+
Rs. 4,744.98
500+
Rs. 4,475.38
1000+
Rs. 3,774.41
Couldn't load pickup availability
Share this product
Description
Description
NAK Wear-Pro Gold Shaft Protection Sleeves: Wear-Pro Sleeve Gold is an advanced design that is used in harsh operating applications. This product offers improved resistance to abrasive wear. The Wear-Pro sleeve gold is particularly effective in high-dust and grit environments, especially when combined with a seal manufactured in Fluorocarbon rubber material.
Benefits: Simple and quick installation, cost-effective, high-grade surface
- Brand / Quality:
- NAK - High Quality
- Width:
- 1 inch
- Material:
- SAE 30304 Hardened Stainless
- Shaft Diameter:
- 4.188 inch
- Flange Diameter:
- 4.5 inch
Technical
Technical
| Shaft Diameter Range (A) | 4.183-4.191 inch |
|---|---|
| Nominal Shaft Diameter (A) | 4.188 inch |
| Flange Diameter (D) | 4.5 inch |
| Width on Shaft (X) | 0.811 inch |
| Overall Width (Y) | 1 inch |
| Installation Depth (Z) | 1.374 inch |
| Flange Diameter (D) Tolerance | 1.6mm |
| Width on Shaft (X) Tolerance | 0.8mm |
| Overall Width (Y) Tolerance | 0.8mm |
