SKU: SLG144_NAK
NAK SLG144 Hardened Stainless Sleeve for Shafts 74.930-75.080mm - Allow 7-10 Days
NAK SLG144 Hardened Stainless Sleeve for Shafts 74.930-75.080mm - Allow 7-10 Days
Regular price
Rs. 3,400.18
Regular price
Sale price
Rs. 3,400.18
Taxes included.
In stock
Price Break
5+
Rs. 3,366.18
10+
Rs. 3,230.17
20+
Rs. 3,162.17
50+
Rs. 3,060.16
100+
Rs. 2,992.16
500+
Rs. 2,822.15
1000+
Rs. 2,380.13
Description
Description
NAK Wear-Pro Gold Shaft Protection Sleeves: Wear-Pro Sleeve Gold is an advanced design that is used in harsh operating applications. This product offers improved resistance to abrasive wear. The Wear-Pro sleeve gold is particularly effective in high-dust and grit environments, especially when combined with a seal manufactured in Fluorocarbon rubber material.
Benefits: Simple and quick installation, cost-effective, high-grade surface
- Brand / Quality:
- NAK - High Quality
- Width:
- 26mm
- Material:
- SAE 30304 Hardened Stainless
- Shaft Diameter:
- 75mm
- Flange Diameter:
- 84mm
Technical
Technical
| Shaft Diameter Range (A) | 74.930-75.080mm |
|---|---|
| Nominal Shaft Diameter (A) | 75mm |
| Flange Diameter (D) | 84mm |
| Width on Shaft (X) | 22mm |
| Overall Width (Y) | 26mm |
| Installation Depth (Z) | 33.4mm |
| Flange Diameter (D) Tolerance | 1.6mm |
| Width on Shaft (X) Tolerance | 0.8mm |
| Overall Width (Y) Tolerance | 0.8mm |
