SKU: SL3/4-RHP

RHP SL3/4 Two Bolt Cast Iron Pillow Block and 3/4 Bore Grub Screw Full Width Insert

RHP SL3/4 Two Bolt Cast Iron Pillow Block and 3/4 Bore Grub Screw Full Width Insert
Rs. 4,343.68
Rs. 4,343.68
Sale Sold out
Taxes included.

In stock

Price Break
10+ Rs. 3,865.88
19+ Rs. 3,648.69
29+ Rs. 3,605.25
39+ Rs. 3,561.82
49+ Rs. 3,518.38
74+ Rs. 3,474.94
99+ Rs. 3,257.76
199+ Rs. 3,214.32
249+ Rs. 3,170.89
499+ Rs. 3,127.45
999+ Rs. 3,040.58
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

RHP SL Series Plummer / Pillow Housings: Supplied with a sealed full width bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation.
The inserts can be removed from the housings for future replacement as required.
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
RHP - High Quality
Inside Diameter:
19.05mm = 0.75 (3/4) inch
Style:
SL
Bolt Hole Centres:
3.484-3.957 inch
Technical
Bore 3/4 inch
L 4.98 inch
H 1.25 inch
H1 0.492 inch
H2 2.508 inch
J max 3.957 inch
J min 3.484 inch
G 0.375 inch
A 1.26 inch
A1 0.886 inch
B 1.219 inch
s 0.502 inch
s1 0.298 inch
d1 1.122 inch
Dynamic load Cr 12800 N
Static load Cor 6650 N
Rec max speed 6700 rpm
Insert <a href="advanced_search_result.php?keywords=1020-3/4G+insonly">1020-3/4G Click Here</a>
Casting group 2
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
