SKU: MST1.1/4-RHP
RHP MST1-1/4 Cast Iron Take Up Unit and 1-1/4 inch Bore Insert
RHP MST1-1/4 Cast Iron Take Up Unit and 1-1/4 inch Bore Insert
Regular price
Rs. 8,857.11
ex VAT
Regular price
Sale price
Rs. 8,857.11
ex VAT
In stock
Price Break
10+
Rs. 7,882.83
19+
Rs. 7,439.97
29+
Rs. 7,351.40
39+
Rs. 7,262.83
49+
Rs. 7,174.26
74+
Rs. 7,085.69
99+
Rs. 6,642.83
199+
Rs. 6,554.26
249+
Rs. 6,465.69
499+
Rs. 6,377.12
999+
Rs. 6,199.98
Couldn't load pickup availability
Description
Description
|
RHP MST Series Cast Iron Take Up Housing Units: Take up type cast iron bearing unit supplied with a sealed heavy duty full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 31.75mm = 1.25 (1-1/4) inch
- Style:
- MST
Technical
Technical
| Bore | 1-1/4 inch |
|---|---|
| L | 4.547 inch |
| L1 | 2.823 inch |
| L2 | 0.492 inch |
| L3 | 0.65 inch |
| L4 | 2.539 inch |
| L5 | 1.693 inch |
| H | 3.996 inch |
| H1 | 2.539 inch |
| H2 | 1.476 inch |
| H3 | 3.504 inch |
| N | 0.886 inch |
| A | 1.437 inch |
| A1 | 1.181 inch |
| A2 | 0.531 inch |
| B | 1.688 inch |
| B5 | - inch |
| s | 0.69 inch |
| d1 | 1.838 inch |
| d4 | - inch |
| Dynamic load | 25700 N |
| Static load | 15300 N |
| Rec max speed | 4500 rpm |
| Weight | 1.6 kg |
| Insert | <a href="advanced_search_result.php?keywords=1035-1-1/4G+insonly">1035-1-1/4G Click Here</a> |
| Casting group | 2 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
