SKU: MSF2-RHP
RHP MSF2 Imperial Four Bolt Square Cast Iron Flange Housing and 2 inch Bore Grub Screw Insert
RHP MSF2 Imperial Four Bolt Square Cast Iron Flange Housing and 2 inch Bore Grub Screw Insert
Regular price
Rs. 16,626.38
ex VAT
Regular price
Sale price
Rs. 16,626.38
ex VAT
In stock
Price Break
10+
Rs. 14,797.48
19+
Rs. 13,966.16
29+
Rs. 13,799.90
39+
Rs. 13,633.63
49+
Rs. 13,467.37
74+
Rs. 13,301.10
99+
Rs. 12,469.79
199+
Rs. 12,303.52
249+
Rs. 12,137.26
499+
Rs. 11,970.99
999+
Rs. 11,638.47
Couldn't load pickup availability
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- MSF
- Bolt Hole Centres:
- 129.997mm = 5.118 inch
Technical
Technical
| Bore | 2 inch |
|---|---|
| L | 6.374 inch |
| H | 5 inch |
| J | 5.118 inch |
| G | 0.625 inch |
| A | 1.72 inch |
| A1 | 2.532 inch |
| A4 | 0.689 inch |
| B | 2.187 inch |
| s | 0.877 inch |
| d1 | 2.709 inch |
| Dynamic load cr | 43500 N |
| Static load Cor | 29200 N |
| Rec max speed | 3100 rpm |
| Weight | 4 kg |
| Insert | <a href="advanced_search_result.php?keywords=1055-2G+insonly">1055-2G Click Here</a> |
| Casting group | 6 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
