SKU: MSF2.3/4-RHP
RHP MSF2-3/4 Imperial Four Bolt Square Cast Iron Flange Housing and 2-3/4 inch Bore Grub Screw Insert
RHP MSF2-3/4 Imperial Four Bolt Square Cast Iron Flange Housing and 2-3/4 inch Bore Grub Screw Insert
Regular price
Rs. 35,662.70
ex VAT
Regular price
Sale price
Rs. 35,662.70
ex VAT
In stock
Price Break
10+
Rs. 31,739.80
19+
Rs. 29,956.67
29+
Rs. 29,600.04
39+
Rs. 29,243.41
49+
Rs. 28,886.79
74+
Rs. 28,530.16
99+
Rs. 26,747.03
199+
Rs. 26,390.40
249+
Rs. 26,033.77
499+
Rs. 25,677.14
999+
Rs. 24,963.89
Couldn't load pickup availability
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 69.85mm = 2.75 (2-3/4) inch
- Style:
- MSF
- Bolt Hole Centres:
- 152.4mm = 6 inch
Technical
Technical
| Bore | 2-3/4 inch |
|---|---|
| L | 7.736 inch |
| H | 6.24 inch |
| J | 6 inch |
| G | 0.75 inch |
| A | 2.02 inch |
| A1 | 3.185 inch |
| A4 | 0.906 inch |
| B | 3.062 inch |
| s | 1.314 inch |
| d1 | 3.622 inch |
| Dynamic load cr | 66000 N |
| Static load Cor | 49500 N |
| Rec max speed | 2300 rpm |
| Weight | 8.6 kg |
| Insert | <a href="advanced_search_result.php?keywords=1075-2-3/4G+insonly">1075-2-3/4G Click Here</a> |
| Casting group | 9 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
