RHP MSF2-1/2 Imperial Four Bolt Square Cast Iron Flange Housing and 2-1/2 inch Bore Grub Screw Insert
RHP MSF2-1/2 Imperial Four Bolt Square Cast Iron Flange Housing and 2-1/2 inch Bore Grub Screw Insert
Regular price
Rs. 25,047.85
ex VAT
Regular price
Sale price
Rs. 25,047.85
ex VAT
In stock
Price Break
10+
Rs. 22,292.59
19+
Rs. 21,040.19
29+
Rs. 20,789.72
39+
Rs. 20,539.24
49+
Rs. 20,288.76
74+
Rs. 20,038.28
99+
Rs. 18,785.89
199+
Rs. 18,535.41
249+
Rs. 18,284.93
499+
Rs. 18,034.45
999+
Rs. 17,533.50
Couldn't load pickup availability
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 63.5mm = 2.5 (2-1/2) inch
- Style:
- MSF
- Bolt Hole Centres:
- 149.23mm = 5.875 inch
Technical
Technical
| Bore | 2-1/2 inch |
|---|---|
| L | 7.382 inch |
| H | 6.122 inch |
| J | 5.875 inch |
| G | 0.625 inch |
| A | 1.874 inch |
| A1 | 3.06 inch |
| A4 | 0.709 inch |
| B | 2.938 inch |
| s | 1.19 inch |
| d1 | 3.425 inch |
| Dynamic load cr | 61000 N |
| Static load Cor | 45000 N |
| Rec max speed | 2450 rpm |
| Weight | 6.8 kg |
| Insert | <a href="advanced_search_result.php?keywords=1070-2-1/2G+insonly">1070-2-1/2G Click Here</a> |
| Casting group | 8 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
