SKU: MSF1025-20K-RHP
RHP MSF1025-20K Metric Four Bolt Square Cast Iron Flange Housing and 20mm Bore Taper Sleeve Insert
In stock
Price Break
Couldn't load pickup availability
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing has a taper bore to accommodate the taper sleeve which is tightened using a lock nut to secure to the shaft after installation, the locknut is subsequently secured with the tab washer. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 20mm
- Style:
- MSF
- Bolt Hole Centres:
- 70mm
Technical
| Bore | 20mm |
|---|---|
| L | 95.3mm |
| H | 68mm |
| J | 70mm |
| G | 10mm |
| A | 28.6mm |
| A1 | -mm |
| A4 | 11.1mm |
| B | -mm |
| s | -mm |
| d1 | -mm |
| Dynamic load cr | 14000 N |
| Static load Cor | 7880 N |
| Rec max speed | 6250 rpm |
| Weight | 1 kg |
| Insert | <a href="advanced_search_result.php?keywords=1025K+insonly">1025K Click Here</a> |
| Casting group | SF3 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
