SKU: MSF1.11/16-RHP
RHP MSF1-11/16 Imperial Four Bolt Square Cast Iron Flange Housing and 1-11/16 inch Bore Grub Screw Insert
RHP MSF1-11/16 Imperial Four Bolt Square Cast Iron Flange Housing and 1-11/16 inch Bore Grub Screw Insert
Regular price
Rs. 13,228.67
ex VAT
Regular price
Sale price
Rs. 13,228.67
ex VAT
In stock
Price Break
10+
Rs. 11,773.52
19+
Rs. 11,112.08
29+
Rs. 10,979.80
39+
Rs. 10,847.51
49+
Rs. 10,715.22
74+
Rs. 10,582.94
99+
Rs. 9,921.50
199+
Rs. 9,789.22
249+
Rs. 9,656.93
499+
Rs. 9,524.64
999+
Rs. 9,260.07
Couldn't load pickup availability
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 42.86mm = 1.687 (1-11/16) inch
- Style:
- MSF
- Bolt Hole Centres:
- 110.998mm = 4.37 inch
Technical
Technical
| Bore | 1-11/16 inch |
|---|---|
| L | 5.626 inch |
| H | 4.563 inch |
| J | 4.37 inch |
| G | 0.625 inch |
| A | 1.563 inch |
| A1 | 2.383 inch |
| A4 | 0.563 inch |
| B | 2.031 inch |
| s | 0.752 inch |
| d1 | 2.449 inch |
| Dynamic load cr | 35000 N |
| Static load Cor | 23200 N |
| Rec max speed | 3400 rpm |
| Weight | 2.8 kg |
| Insert | <a href="advanced_search_result.php?keywords=1050-1-11/16G+insonly">1050-1-11/16G Click Here</a> |
| Casting group | 5 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
