SKU: MSF1.1/4-RHP
RHP MSF1-1/4 Imperial Four Bolt Square Cast Iron Flange Housing and 1-1/4 inch Bore Grub Screw Insert
RHP MSF1-1/4 Imperial Four Bolt Square Cast Iron Flange Housing and 1-1/4 inch Bore Grub Screw Insert
Regular price
Rs. 5,981.14
ex VAT
Regular price
Sale price
Rs. 5,981.14
ex VAT
In stock
Price Break
10+
Rs. 5,323.21
19+
Rs. 5,024.16
29+
Rs. 4,964.35
39+
Rs. 4,904.53
49+
Rs. 4,844.72
74+
Rs. 4,784.91
99+
Rs. 4,485.86
199+
Rs. 4,426.04
249+
Rs. 4,366.23
499+
Rs. 4,306.42
999+
Rs. 4,186.80
Couldn't load pickup availability
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 31.75mm = 1.25 (1-1/4) inch
- Style:
- MSF
- Bolt Hole Centres:
- 91.999mm = 3.622 inch
Technical
Technical
| Bore | 1-1/4 inch |
|---|---|
| L | 4.626 inch |
| H | 3.752 inch |
| J | 3.622 inch |
| G | 0.5 inch |
| A | 1.236 inch |
| A1 | 1.827 inch |
| A4 | 0.5 inch |
| B | 1.688 inch |
| s | 0.69 inch |
| d1 | 1.838 inch |
| Dynamic load cr | 25700 N |
| Static load Cor | 15300 N |
| Rec max speed | 4500 rpm |
| Weight | 1.7 kg |
| Insert | <a href="advanced_search_result.php?keywords=1035-1-1/4G+insonly">1035-1-1/4G Click Here</a> |
| Casting group | 2 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
