SKU: MSF1.1/2-RHP
RHP MSF1-1/2 Imperial Four Bolt Square Cast Iron Flange Housing and 1-1/2 inch Bore Grub Screw Insert
RHP MSF1-1/2 Imperial Four Bolt Square Cast Iron Flange Housing and 1-1/2 inch Bore Grub Screw Insert
Regular price
Rs. 10,871.93
ex VAT
Regular price
Sale price
Rs. 10,871.93
ex VAT
In stock
Price Break
10+
Rs. 9,676.02
19+
Rs. 9,132.42
29+
Rs. 9,023.70
39+
Rs. 8,914.98
49+
Rs. 8,806.26
74+
Rs. 8,697.54
99+
Rs. 8,153.95
199+
Rs. 8,045.23
249+
Rs. 7,936.51
499+
Rs. 7,827.79
999+
Rs. 7,610.35
Couldn't load pickup availability
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 38.1mm = 1.5 (1-1/2) inch
- Style:
- MSF
- Bolt Hole Centres:
- 105.004mm = 4.134 inch
Technical
Technical
| Bore | 1-1/2 inch |
|---|---|
| L | 5.374 inch |
| H | 4.374 inch |
| J | 4.134 inch |
| G | 0.625 inch |
| A | 1.39 inch |
| A1 | 2.133 inch |
| A4 | 0.563 inch |
| B | 1.938 inch |
| s | 0.752 inch |
| d1 | 2.256 inch |
| Dynamic load cr | 32500 N |
| Static load Cor | 20500 N |
| Rec max speed | 3700 rpm |
| Weight | 2.6 kg |
| Insert | <a href="advanced_search_result.php?keywords=1045-1-1/2G+insonly">1045-1-1/2G Click Here</a> |
| Casting group | 4 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
