• RHP MFC60 Four Bolt Round Cast Iron Flanged Bearing Unit and 60mm Insert
1 1

SKU: MFC60-RHP

RHP MFC60 Four Bolt Round Cast Iron Flanged Bearing Unit and 60mm Insert

RHP MFC60 Four Bolt Round Cast Iron Flanged Bearing Unit and 60mm Insert
Rs. 26,352.23 ex VAT
Rs. 26,352.23 ex VAT
Sale Sold out

In stock

Price Break
10+ Rs. 23,453.48
19+ Rs. 22,135.87
29+ Rs. 21,872.35
39+ Rs. 21,608.83
49+ Rs. 21,345.31
74+ Rs. 21,081.78
99+ Rs. 19,764.17
199+ Rs. 19,500.65
249+ Rs. 19,237.13
499+ Rs. 18,973.61
999+ Rs. 18,446.56
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing ,heavy duty full width bearing insert
Brand / Quality:
RHP - High Quality
Inside Diameter:
60mm
Style:
MFC
Pitch Circle Diameter:
165.1mm
Technical
Bore 60mm
L 193.7mm
H 139.7mm
J 165.1mm
G 12mm
A1 46.02mm
A4 15.9mm
A5 12.7mm
B 74.63mm
s 30.23mm
d1 87mm
Dynamic load 61000 N
Static load 45000 N
Rec max speed 2450 rpm
Weight 4.5 kg
Insert <a href="advanced_search_result.php?keywords=1070-60G+insonly">1070-60G Click Here</a>
Casting group 7
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
