SKU: MFC4-RHP
RHP MFC4 Four Bolt Round Cast Iron Flanged Bearing Unit and 4 inch Insert
RHP MFC4 Four Bolt Round Cast Iron Flanged Bearing Unit and 4 inch Insert
Regular price
Rs. 103,710.70
ex VAT
Regular price
Sale price
Rs. 103,710.70
ex VAT
In stock
Price Break
10+
Rs. 92,302.52
19+
Rs. 87,116.99
29+
Rs. 86,079.88
39+
Rs. 85,042.77
49+
Rs. 84,005.67
74+
Rs. 82,968.56
99+
Rs. 77,783.03
199+
Rs. 76,745.92
249+
Rs. 75,708.81
499+
Rs. 74,671.70
999+
Rs. 72,597.49
Couldn't load pickup availability
Description
Description
|
RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 101.6mm = 4 inch
- Style:
- MFC
- Pitch Circle Diameter:
- 260.35mm = 10.25 (10-1/4) inch
Technical
Technical
| Bore | 4 inch |
|---|---|
| L | 11.748 inch |
| H | 9 inch |
| J | 10.25 inch |
| G | 0.75 inch |
| A1 | 3.5 inch |
| A4 | 1.811 inch |
| A5 | 0.5 inch |
| B | 4.625 inch |
| s | 1.94 inch |
| d1 | 5.135 inch |
| Dynamic load | 157000 N |
| Static load | 122000 N |
| Rec max speed | 1600 rpm |
| Weight | 17.7 kg |
| Insert | <a href="advanced_search_result.php?keywords=3095-4G+insonly">3095-4G Click Here</a> |
| Casting group | 11 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
